How does the tea seed peeling machine work
The tea seed sheller is a professional equipment used for tea seed shelling. The following is a detailed introduction to its working principle:
workflow
- Tea seeds (or tea fruits with tea seeds) are fed into the feeding hopper through an air feeding device and enter the front drum.
- The front drum uses specially designed patterned plates and curved grids (or shed strip concave plates) to separate the tea seed shells from the kernels through squeezing force.
- The peeled tea seed kernels and shells fall together through the front arc-shaped grid (or front concave plate hole) and pass through the air duct.
- During this process, the strong wind of the wind turbine blows most of the tea seed shells out of the machine, leaving only the tea seed kernels and some un peeled tea seed fruits.
- Tea seed kernels and small tea seed fruits are sent to a specific gravity sieve for sorting.
- The sorted tea seed kernels rise from the top and flow out through the kernel outlet.
- The tea seeds and small fruits that cannot be peeled off will descend from the bottom of the sorting screen, enter the lifting device, and then enter the rear drum for peeling.
- After being peeled off, the Renhe shell falls down through a curved grid and is then screened again by the wind selection and specific gravity sorting screen of the wind turbine to ensure that each tea seed undergoes the screening process.
Machine composition
The tea seed sheller usually consists of a frame, fan, motor, screen mesh, feeding hopper, vibrating screen, V-belt pulley and its transmission V-belt, and other components.
Machine features
- Versatile functions: It integrates tea seed peeling, shell and kernel separation, and also has functions such as impurity removal, peeling, and sorting.
- High stripping rate: The tea seeds processed by the tea seed shelling machine have low crushing rate, clean sorting, good color, and few impurities, and all indicators meet national standards.
- Efficient production: No need to expose oil tea fruits to direct sunlight beforehand, the hourly yield can reach around 800kg~1200kg.
- Convenient operation: The tea seed sheller has the advantages of simple structure, light weight, low power consumption, high productivity, and easy operation and maintenance.
- Safe and reliable: The tea seed peeling machine also has the characteristics of low noise, labor-saving, and high degree of automation, which can purify the production environment.
In summary, the tea seed shelling machine achieves fast and efficient shelling of tea seeds through a series of complex and orderly processes, and is an important equipment in the tea processing industry.
